阀体规格 Size | DN10-DN100 | 防护等级 Protection | IP65 |
连接形式Connection type | 螺纹式、焊接式、法兰式、快装式
Threadedi, Welded, Flanged, Tri-clamp | 介质压力Medium Pressure | ≤1.0MPa |
介质温度Medium Temperature | -10℃—+180℃,+25℃— +220℃ | 气源压力Air Pressure | 0.3~0.7MPa |
环境温度 Ambient Temperature | 0~+55℃(高温型可单独订购)
Customization for high temperature available) | 控制电源 Control Power | 24VDC±10% |
气源质量要求
Air quality requirements | 清洁干燥的空气，气体质量符合ISO8573-1
Clean and dry air, gas CuJaliy accard with ISO8573-1 | 阀门设定信号 valve set signal | 0/4 ~20 mA or 0 ~5/10v |
最大固体颗粒密度
Maximum derisity of solid particles | 10mgm3 | 功耗 Power consumption | <5w |
最大颗粒直径
Maximum particle diameter | 40um | 设定信号输入阻抗
lnput sigrial impedance | 04-20 mA input signal 240 .
0-5/10 input signal 21 k Q |
最大含油量
Maximum oil content | 25mg/m3 | 模拟输出信号
Analog output signal | 04-20 20mA信号时Max load 560o.
0-5/10V信号时Max currenit 10mA |
